M5 Corpus
Made for More
The M5 Corpus delivers high-performance motors with a 7.5 mph top speed and low-end torque for precise control. FlexLink Pro independent suspension ensures stability and comfort as it remains active even with 14” seat elevation. Now supporting users up to 330 lbs., the M5 Corpus combines power and advanced functionality.
More Adventure
Conquer More
More Visible
Designed for Independence
Permobil redesigned the knee supports necessary for standing and has created a lightweight, swing-away option that is 75% lighter than the original single-post design. It features improved comfort and allows for a more precision fit thanks to the integrated BOA® Fit System dial for micro adjustments. When you are ready to place or remove the knee supports, the looped release mechanism lets you take care of it independently since it works for a wide variety of hand functions. You’ll love the convenient on-chair storage along the seat rail which keeps the knee supports close at hand, but out of the way when not standing!
| Specification | Value |
|---|---|
| Maximum User Weight | 330 lb |
| Maximum Speed | 7.5 mph |
| Minimal Seat Width | 17″ |
| Maximum Seat Width | 23″ |
| Minimal Seat Depth | 14″ |
| Maximal Seat Depth | 22″ |
| Driving Range | 20 km |
| Base Width | 25″ |
| Base Length | 37.5″ |
| Minimum Turning Radius | 21.5″ |
| Ground Clearance | 3″ |
| Drive Electronics | R-net 120A |
| Battery Type | Group 24 |
| Seat to Floor Height | 17.5″, 18.5″, 19.5″ |
| Power Tilt Options | 0°–50° (Posterior), 5°, 10°, 20° (Anterior) |
| Recline Options | 85°–120° (manual), 85°–180° (power) |
| Legrest Elevation | 85°–180° |
| Armrest Pad Lengths | 13″, 16″, 18″ |
| Backrest Heights | 20″, 23″–28″ (1″ increments) |
| Optional Seat Elevator | 14″ |
| Drive Wheel | 14″ |
| Casters | 8″ |
| Weight Including Batteries | 423 lb |
