F5 Corpus VS
Stand Without Compromise
The F5 Corpus VS is a power standing wheelchair featuring programmable standing sequences using supine, semi-reclined, or sit-to-stand techniques. Further customize your standing position with adjustable chest support, multiple knee support options, and a power articulating footplate. Available with Group 3 and Group 4 base codes, it offers accessibility and versatility. The F5 Corpus VS now includes Power Platform electronics with a modern joystick display and utilizes QuickConfig for simplified programming.
Designed for Independence
Permobil redesigned the knee supports necessary for standing and has created a lightweight, swing-away option that is 75% lighter than the original single-post design. It features improved comfort and allows for a more precision fit thanks to the integrated BOA® Fit System dial for micro adjustments. When you are ready to place or remove the knee supports, the looped release mechanism lets you take care of it independently since it works for a wide variety of hand functions. You’ll love the convenient on-chair storage along the seat rail which keeps the knee supports close at hand, but out of the way when not standing!
| Specification | Value |
|---|---|
| Maximum User Weight | 300 lb |
| Maximum Speed | 5.8 mph (Group 3), 7.5 mph (Group 4) |
| Minimal Seat Width | 17″ |
| Maximum Seat Width | 23″ |
| Minimal Seat Depth | 14″ |
| Maximal Seat Depth | 22″ |
| Driving Range | 20 km |
| Base Width | 25.5″ |
| Base Length | 43″ |
| Minimum Turning Radius | 30″ |
| Ground Clearance | 3″ |
| Drive Electronics | R-net 120A |
| Battery Type | Group 24 Gel |
| Seat Elevator | 14″ |
| Seat to Floor Height | 17.5″, 18.5″, 19.5″ |
| Power Tilt Options | 0°–50° Posterior, 45° Anterior |
| Recline Options | 85°–180° (Power) |
| Legrest Elevation | 90°–180° |
| Armrest Pad Lengths | 10″, 13″, 16″, 18″ |
| Backrest Heights | 23″–28″ (by 1″ increments) |
| Weight Including Batteries | 432 lb |
